Waypointaxle products are defined by precise numerical specifications that determine suitability for various applications. These numbers cover load ratings, dimensions, and material properties, helping users select the right components for trailers, vehicles, and industrial equipment. Understanding these figures ensures safe operation and optimal performance over time.

Load Capacity and Weight Ratings

Waypointaxle load ratings indicate the maximum weight each axle can support under standard conditions. Common figures include 3500-pound, 5200-pound, and 7000-pound capacities, measured at the hub. Gross axle weight rating, or GAWR, combines axle strength with tire and wheel limits. Always verify that combined axle ratings exceed the total loaded weight of the trailer or vehicle. Overloading beyond these numbers can lead to premature wear, reduced braking efficiency, and safety risks. Spring center measurements, typically ranging from 40 to 60 inches, affect stability and must match the frame width for even weight distribution.

Dimensions and Hub Specifications

Physical measurements form another critical set of Waypointaxle numbers. Axle tube diameters often measure 2.375 inches or 3 inches, influencing bending resistance. Overall lengths vary from 60 to 96 inches depending on the model, with track widths standardized for common tire sizes. Hub face to hub face distance ensures proper wheel alignment. Bolt patterns such as 5 on 4.5 inches or 6 on 5.5 inches determine compatibility with wheels. Bearing sizes, like 1.5-inch inner and 1.25-inch outer, dictate maintenance intervals and replacement parts. These dimensions remain consistent across production batches for interchangeability.

Material and Torque Specifications

Material strength numbers include yield strength ratings above 50,000 psi for high-carbon steel construction. Wall thickness of 0.25 inches or greater provides durability against road impacts. Torque values for spindle nuts range from 150 to 250 foot-pounds depending on axle size, preventing bearing damage during installation. Brake torque specifications reach 2000 pound-feet on electric brake models. These values guide proper assembly and routine inspections. Regular checks against manufacturer tables keep systems within safe operating parameters for extended service life.
